Is a tissue processing technology for fixation, dehydration, clearing, and infiltration.
Standard procedure for 4 mm specimens in less than 2 hours.
2 mm specimens in less than 1 hours.
Needle biOpsies in 30 minutes.
Saving 60% of the reagent in respect to the conventional tissue processing.
Our technology and l-iistosafe reagent provide superior staining quality when compared with conventional tissue processing: they provide exceptionally sharp morphology and nuclear details.
Histo Process 400 is engineered for all types of specimens up to 5 mm, including fatty specimens such as breast tissue. No pre-sorting or special grossing. No risk of over-fixation or the need to perform recommended antigen retrieval procedures.
Automatic loading from 5 liter tank pre-filied by the quick connector of the instrument without unscrewing the cap of tank.
Automatic discharge of reagents and wax in a separate waste tank placed in the compartment under the instrument.
The instrument is closed by a lid and it is equipped with an active carbon filter to extract solvent fumes
The system allows to process the tissues continuously according to the established schedule with a minimum interval of 20 minutes for each process chambre.
Possibility to use conventional solvent and recommended Histosafe solvent.
Histo Process 300 technology is excellent for: Immunohistochemistry, genome and proteome analysis, RNA and DNA expression analysis, DNA or RNA extraction.
A dehydration and clearing eco solvent for biological tissue processing, green molecule non toxic, harmless and with a low environmental impact.
Xylene free, isoparaffin free.
Speeds up and simplifies the steps in tissue processing.
Replaces the complete range of alcohol and xylene or substitutes before the paraffin infiltration.
Enables maximum penetration and efficiency.
It preserves the cytoskeletai and protein structure for a high improvement in tissue morphology.
in immunohistochemistry it improves the chromogenic definition in the histological slide result providing more viewing details and sharper vision.
Allows the use of molecular biology methods after processing steps improving the concentration and the quality of DNA from FFPE tissues for a best extrating DNA from archivial FFPE tissues.
Low impact in the professional environment in accordance with International Directives and safety rules in the work environment.
The system is composed of four stainless steel chambers with a capacity of 5 liters. The temperature process chambers can be adjusted up to 80°C.
Rapid pre-heating system that warming the solvent in about 2 minutes.
Pre-filled tank of reagent with quick connector without unscrewing the cap.
Separate waste tank for exhausted reagent and wax, placed in the compartment under the instrument.
20 programs for different processing techniques productivity: 300 cassettes per basket.
Continuously according to the established schedule with a minimum interval of 20 minutes for each process chambre.
Instrument closed by a lid and equipped with an active carbon filter to extract solvent fumes.
Dimensions: 1100 x 900 x 1600 h mm. Weigth: 100 kg.
230V 50 Hz 900W.
